KP-1403-88
- Specification
- Product Description
- Product Scenario
- Product Advantage
| Model | Pressure (kg/cm2) |
Speed (r.p.m.) |
Displacement (cm3/rev.) |
Valve Control Wire Actuating Pressure (kg) |
Shaft Diameter (mm) |
Shaft Rotation | Oil | Weight (kg) |
||
|---|---|---|---|---|---|---|---|---|---|---|
| Max. | Rated | Max. | Min. | |||||||
| KP-1403-88 | 250 | 80 | 1800 | 350 | 136.1 | 15 | 30 |
A: Counterclockwise/ |
Mobil DTE 32 or equivalent | 38 |
Performance Curve
The KP-1403-88 is an industrial-grade, heavy-duty pneumatic dump truck hydraulic pump manufactured by Hung Rong Hydraulic Tech. Co., Ltd. Engineered for demanding high-volume fluid transfer, it delivers consistent performance across extended duty cycles.
- Displacement: 136.1 cm³/rev
- Rated Pressure: 80 kg/cm²
- Maximum Pressure: 250 kg/cm²
- Speed Range: 350 - 1800 rpm
- Rotation: Clockwise and Counterclockwise (Bi-directional)
- Shaft Diameter: 30 mm
- Actuating Pressure: 15 kg (valve control wire)
- Product Weight: 38 kg
- Heavy Dump Truck Systems: Meet demanding lifting requirements and high-volume fluid transfer.
- OEM System Integration: Adapts perfectly to various factory chassis layouts due to its dual-rotation design.
- Global Fleet Operations: Fits a wide range of commercial vehicles globally using universally standard hydraulic oils.
- Extended Duty Applications: Formulated to maintain stable continuous output under high-frequency loading tasks.
Pneumatic hose
Copper pipe joint
- High-Volume Fluid Transfer: Large displacement shortens cycle times and significantly boosts field efficiency.
- Reduced Inventory Complexity: Single model supports both CW and CCW rotation, lowering spare part costs for fleets.
- Low-Effort Responsive Control: Requires only 15 kg of actuating pressure for light yet precise load management.
- Excellent Oil Compatibility: Fully compatible with standard Mobil DTE 32 or equivalent hydraulic oils.
- Industrial-Grade Standards: Robust construction ensures reliable service life under harsh commercial environments.
