| Model | Pressure (kg/cm2) |
Speed (r.p.m.) |
Displacement (cm3/rev.) |
Valve Control Wire Actuating Pressure (kg) |
Shaft Diameter (mm) |
Shaft Rotation | Oil | Weight (kg) |
||
|---|---|---|---|---|---|---|---|---|---|---|
| Max. | Rated | Max. | Min. | |||||||
| KP-75 | 250 | 70 | 1800 | 350 | 72 | 14 | 25 | Counterclockwise | Mobil DTE 32 or equivalent | 21 |
Performance Curve
The KP-75 is a heavy-duty dump truck hydraulic pump manufactured by Hung Rong Hydraulic Tech. Co., Ltd. Engineered for demanding hydraulic systems, it delivers exceptional lifting force under heavy loads.
- Displacement: 72 cm³/rev
- Rated Pressure: 70 kg/cm²
- Maximum Pressure: 250 kg/cm²
- Speed Range: 350 - 1800 RPM
- Rotation: Counterclockwise (CCW)
- Shaft Diameter: 25 mm
- Actuating Pressure: 14 kg (valve control wire)
- Product Weight: 21 kg
- Dump Truck Systems: Powers heavy-duty lifting mechanisms.
- Fleet Integration: Fits commercial and industrial vehicle fleets.
- Varying Conditions: Operates across diverse field environments.
- System Retrofitting: Integrates smoothly into existing hydraulic setups.
- High-Pressure Performance: Handles extreme loads with ease.
- Precise Control: Responsively manages loads via 14 kg actuation.
- Operational Flexibility: Adapts broadly with a wide speed range.
- Oil Compatibility: Works with Mobil DTE 32 or equivalent.
- Robust Construction: Ensures dependable service life and durability.
