705-52-32001
- Specification
- Product Description
- Product Scenario
- Product Advantage
| Model | Displacement (cm3/rev.) |
Max. Pressure (kg/cm2) |
Rated Pressure (kg/cm2) |
Speed (r.p.m.) |
|
|---|---|---|---|---|---|
| Max. | Min. | ||||
| SAR3-080 | 80.0 | 250 | 210 | 2500 | 600 |
| SAR3-080 | 80.0 | ||||
Applicable to :
HD605-5, HD465-5, HD465-3
- Part Number: 705-52-32001
- Model: SAR3-080+080
- Compatible Equipment: Komatsu heavy-duty dump trucks (HD605-5, HD465-5, HD465-3)
- Manufacturer: HUNG RONG HYDRAULIC TECH. CO., LTD. (Taiwan)
⚙️ Technical Specifications
- Displacement: 80.0 cm³/rev (per section)
- Rated Pressure: 210 kg/cm²
- Max Operating Pressure: 250 kg/cm²
- Speed Range: 600 – 2500 r.p.m.
- Dual Hydraulic Circuits: The tandem design supplies the necessary power simultaneously for steering, dump bed lifting, and auxiliary systems.
- Severe-Duty Performance: Engineered specifically for high-load, continuous cycles in demanding off-highway mining and construction environments.
- High Efficiency: Precision-machined components guarantee proper clearances and seal integrity, minimizing internal leakage even under continuous high pressure.
- Multi-Model Compatibility: Direct-fit replacement for Komatsu part 705-52-32001 across three truck models, reducing inventory complexity for fleet operators.
- Extended Service Life: High volumetric efficiency allows for longer service intervals, significantly reducing unplanned downtime and maintenance costs.
- Taiwan R&D Expertise: Manufactured by an established hydraulic specialist with rigorous quality control, delivering OEM-equivalent fit and performance.
- Lower Cost of Ownership: Provides a highly reliable, cost-effective aftermarket solution that maintains maximum operational productivity and equipment uptime.
