BRAND

KOMATSU

PART NO

07433-71103

MODEL NO

CGP5-48

Q'TY

Model	Displacement (cm³/rev.)	Rotation Direction	Speed (r.p.m.)	Inlet (mm)	Outlet (mm)
Max.	Min.
CGP5-48	52.5	Counterclockwise	3200	600	Ø 27	Ø 13 M24*P1.5 DEPTH 20

Model

Displacement
(cm³/rev.)

Rotation

Direction

Speed
(r.p.m.)

Inlet

(mm)

Outlet

(mm)

Max.

Min.

CGP5-48

52.5

Counterclockwise

3200

600

Ø 27

Ø 13

M24*P1.5

DEPTH 20

Applicable to :

D85A-12 , D155C-1 , D155C-1P-ZZ , D155C-1P , D135A-2 , D150A-1 , D155A-2A , D155A-1 , D155A-2 , D135A-1 , D135A-2 , D155S-1
